Product introduction

Speaker cable

20-12AWG Transparent Color Speaker Cable
SKU:
Availability:
Quantity:

Product Description

0公司名称

new cetification

Speaker  Cable



竖卷形: Speaker CableStructure

Material

Specification

Core No.

-

2~8

Conductor

BC

20-12AWG

Insulation

PVC

0.6-0.8mm Thickness

1st Shield

Selectable

-

2nd Shield

Selectable

-

Drain Wire

-

-

Jacket

PVC

0.6-1.1mm Thickness



Normal area(mm2)

Structure

Insulation thickness(mm)

Overall dia.(mm)

Normal area(mm2)

Structure(mm)

Insulation thickness(mm)

Overall dia.(mm)

2x0.50

2x9/0.10

0.7

2.20x4.40

2x0.50

28/0.15

0.8

2.40x4.80

2x0.75

2x14/0.10

0.7

2.40x4.80

2x0.75

42/0.15

0.8

2.50x5.00

2x1.00

2x18/0.10

0.8

2.60x5.20

2x1.00

32/0.20

0.8

2.80x5.70

竖卷形: Speaker Cable2x1.50

2x27/0.10

0.9

3.10x6.20

2x1.50

48/0.20

0.9

3.20x6.50

2x2.00

2x36/0.10

1

3.90x7.80

2x2.50

49/0.25

0.9

3.60x7.40

2x2.50

2x45/0.10

1.2

4.20x8.40

2x4.00

56/0.30

1

4.30x8.80

2x4.00

2x72/0.10

1.3

4.80x9.60

2x6.00

84/0.30

1

4.80x9.80



2-12公司介绍4包装

1) Coil With Carton

100M/Coil, 6 Coil/Carton
  200M/Coil, 300M/Coil, 2 Coil/Carton
  Other Length: 20Yard/Coil, 30Yard/Coil, 60Yard/Coil, 100Yard/Coil.

2). Reel With Pallet or Not

100M/Paper Reel
  100M/Plastic Reel, 200M/Palstic Reel, 305M/Plastic.
  305M/Wooden Reel, 500M/Wooden Reel

3). Reel In Box, With Pallet

500ft Reel In Box.
  1000ft/Reel In Box.
  Color Box  and OEM Package available.


4) Other packing available according to client's request

3证书7展会

Our Main products:
1) 75 Ohm Coaxial Cable:
RG59, RG6, RG7, RG11, etc.
2) 50 Ohm Coaxial Cable:
RG58, RG142, RG174, RG178, RG213, RG214, RG316, etc.
3) MIL-C-17 Military Standard Cable:
RG59 A/U, RG59 B/U, RG6 A/U, RG11 A/U, RG58 A/U, RG58 B/U, RG58 C/U, RG213, RG214, etc.
4) Trunk Distribution Cable:
P3.412 JCA/JCAM, P3.500 JCA/JCAM, P3.565JCA/JCAM, QR320 JCA/JCAM, QR540
